Name: Fully Automatic Extrusion Petottle Blow Molding Machine 3.43*2.3*2.65MM
Brand: faygo
SKU: HTII5L
Price: 50000 USD
Availability: InStock
Rating: 4.8 (165 reviews)

Rumah Produk Blow Molding Machine

Fully Automatic Extrusion Petottle Blow Molding Machine 3.432.32.65MM

Detail produk:

Place of Origin:	Zhangjiagang,Jiangsu
Nama merek:	faygo
Sertifikasi:	CE &ISO
Model Number:	HTII5L

Syarat-syarat pembayaran & pengiriman:

Minimum Order Quantity:	1set
Harga:	50000USD
Packaging Details:	wooden box and PE film
Delivery Time:	5-8days
Payment Terms:	Western Union, T/T, D/P, D/A, L/C

Kontak

Detil Deskripsi produk

Color:	Blue	Station:	Double
Max product volume:	5L	Screw heating power:	3
Size:	3.432.32.65
Cahaya Tinggi:	bottle blow moulding machine , plastic bottle production machine

Product Description :

Product Details :Fully automatic Extrusion blow molding machine HT(II)-5L

Technical Specification :

Max product Volume	(L)	5
Station		Double
Dry cycle	(pc/h)	700*2
Screw Diameter	(mm)	70
Screw L/D ratio	(L/D)	25
Screw drive power	(KW)	22
Screw heating power	(KW)	6.8~8.2
NO of heating zone (Screw )	(ZONE)	3
Output of HDPE	(kg/h)	70
Hydraulic pump driving power	(KW)	7.5
Clamping force	(KN)	60
Platen distance	(mm)	148~508
Mold moving stroke	(mm)	400
Max .Size of Mold	(W*H)(mm)	370*390
Capacity of Accumulator head	(L)
Max.Die diameter (Single-head)	(mm)	145
Die heating power(Single-head)	(KW)	2.5
No.of heating zone(Single-head)	(ZONE)	3
Central distance of Bi-head	(mm)	160,180
Max. Die diameter (Bi-head)	(mm)	80
No .of heating zone(Bi-head)	(ZONE)	5
Heating Power (Bi-head)	(KW)	2.88
Blowing pressure	(Mpa)	0.6
Air consumption	(M^3/MIN)	0.4
Cooling water pressure	(Mpa)	0.2~0.3
Water consumption	(L/MIN)	60
Size of machine	(LWH)(m)	3.432.32.65
Weight of machine	(TON)	5.5

Packaging &Shipping

Packaging Details: PE film ,Wooden box ,Wooden /Steel base

Delievery Detail :By ship or train

Some pictures of sample

Automatic blow molding machine for 3L hoursehold cleaning bottles

OUR SUPPLIER OF MAIN PARTS

a) Hydraulic parts

Name	Supplier
Oil pump	PARKER OR SUNNY ,America
Valve	YUKEN OR SUNNY
HOSE,JOINT	PARKER SIR
Sealer	TOP DZ Europe

b)Electrial parts

Name	Supplier
Microcomputer control system	MITSUBISHI PLC,JAPAN
Touch Screen HITECH	HITECH color screen ,Taiwan
Temperature controller	MITSUBISHI
Conductor	SCHNERDER
Air switch	SCHNERDER
Motor	SIMENS BEIDE Asychronous motor
Inverter	MITSUBISHI
